Crystal-clear audio and ultra-low latency.
The Allen & Heath SQ-7 digital mixer is a flagship console equipped with high-end components to meet complex mixing needs. Powered by Allen & Heath’s 96 kHz XCVI FPGA engine, the SQ-7 delivers pristine audio quality and ultra-low latency. With 32 premium microphone preamps, 16 XLR outputs, and expandability up to 48 microphones, this mixer boasts a wide range of I/O for large-scale shows.

96 kHz Audio Engine
: At the heart of the SQ-7 is Allen & Heath’s 96 kHz XCVI FPGA engine, delivering high-resolution audio, sub-0.7 ms latency, and optimized dynamic range. This state-of-the-art engine gives the SQ-7 the ability to handle 48 inputs at 96 kHz with ample dynamic range and the ability to run DEEP plugins on all channels.

12 Stereo Mixes for In-Ear Monitoring:
With 12 stereo mixes and parametric and graphic EQ on each, the SQ-7 is an ideal mixer for in-ear monitoring. Its compact and robust design eliminates the need for home monitoring consoles. Every musician can achieve their perfect IEM mix with great control and minimal latency.

Expandable and flexible:
Although the SQ-7 already features extensive I/O, it can be expanded to up to 48 microphone inputs using Allen & Heath rack and stage expanders. You can also network two SQ-7 mixers or connect them to other Allen & Heath digital mixers, such as Qu or dLive, for bidirectional audio. Add a Dante card to integrate with existing audio systems or to provide digital FOH/monitoring splitting.

Additional Features:
The SQ-7 features advanced automatic microphone mixing for conferences and broadcasts, flexible USB recording, and a free iOS app for wireless control. It’s built to withstand the demands of live performances with a rugged, all-metal chassis. You can customize the layout, naming conventions, and color coding to suit your workflow. The SQ-7 offers eight stereo effects engines with emulations of classic reverbs, delays, and more.

Features:
48-channel digital mixer with 96 kHz XCVI FPGA engine,
33 faders
, 32 built-in microphone preamps,
8 stereo effects engines,
automatic microphone mixing

SQ-7 48-Channel Digital Mixer Specifications:
Format
Analog/Digital: Digital
Number of Channels: 48
Buses/Groups: 36
Aux Sends: 8
Powered: No
Inputs
Total Inputs: 48
Mic Preamps: 32
XLR/TRS Combo Jacks: 0
XLR Only Jacks: 32
1/4″ Only Jacks: 2
S/PDIF Input: No
ADAT/Optical Input: No
RCA Input: No
AES/EBU: No
Outputs
Total Outputs: 18
XLR Outputs: 16
1/4″ Outputs: 2
S/PDIF Outputs: 0
ADAT/Optical Outputs: 0
RCA Outputs: No
AES/EBU: 1
Other Connections
Connections: USB
MIDI I/O: USB/TCP-IP
Headphone Outputs: 2
Built-in Effects
Compression: Yes
Reverb: Yes
Delay: Yes
Chorus/Flange: Not Specified
EQ
Type: Graphic
Other
Width: 80 cm
Height: 19.8 cm
Depth: 51.8 cm
Weight: 8.1 kg
Fader type: 100 mm Linear
Motorized faders: Yes
